UNIT AA-1042
AVAILABLE NOW
IN THE BAY 18 DAYS · CLEAN · FLORIDA, IN HAND
2019 Ford F-150 Lariat SuperCrew 4x4
ASKING PRICE
$33,900
VS MARKET
-2%
Mileage
68,420 mi
Condition
91 /100
Power
375 hp
0–60 mph
5.9 s
Measurement sheet
Every reading on one page.
The sheet travels with the car: 120 measured points, the dyno figures, the condition scores and the defect log. Ask for the PDF and you get exactly this, plus the photographs taken in the bay.
MEASURED
Condition by system
7 SYSTEMS
Scores are the weighted result of the 120-point protocol for each system, not an opinion. Red under 82, amber to 90, cyan above.
INSTRUMENTS
Key readouts
BAY LOG
Torque
470 lb-ft
Economy
17 city city
Owners
1
Days on lot
18
DEFECT LOG
3 findings, published
NO MODERATE FINDINGS
Everything the protocol found, including what we decided not to repair. Each finding says what it is and what we did about it — nothing here is hidden behind “sold as seen”.
| Severity | Finding | Action taken |
|---|---|---|
| NOTE | Rear bumper chrome scuffed at tow point | Left as is |
| MINOR | Front rotors measured 26.1 mm (min 26.0 mm) | Replace within 8,000 miles |
| MINOR | Tailgate damper slow in cold weather | Left as is, part quoted |
Model watch list
What this generation is known for.
Every model has faults that show up again and again in the workshop and in the manufacturer’s own bulletins. These are the ones documented for this exact year, engine and transmission — listed whether or not this particular car shows them.
- Cam phaser rattle on cold start — Ford TSB for 2017–2020 3.5L EcoBoost
- Excessive oil consumption — Ford TSB for 2018–2020 3.5L EcoBoost
- 10R80 ten-speed: harsh shifts and CDF drum bushing wear (Ford TSB, class action)
- Turbo wastegate linkage rattle — fixed with Ford spring washer kit HL3Z-9G488-C
Notes on the data
- Curb weight is not published in any Ford document we could reach; the door-jamb figure is the authority for this exact truck.
- Fuel tank and 0–60 figures come from an aggregator and a 2017 test of the mechanically identical truck, not a 2019-specific test.
- Towing and payload are Ford maximums for this cab, box and drivetrain with the Max Trailer Tow package — an as-built Lariat with options carries less.
Specifications verified against
BUILD SHEET
Specification
1FTEW1E4•••••412
- Stock number
- AA-1042
- Body
- Truck
- Engine
- 3.5L EcoBoost V6
- Power
- 375 hp @ 5,000 rpm
- Torque
- 470 lb-ft @ 3,500 rpm
- Transmission
- 10-speed automatic
- Drivetrain
- 4WD
- 0–60 mph
- 5.9 s
- Curb weight
- 4,970 lb
- Seating
- 5
- Dimensions
- 231.9 in long · 79.9 wide · 77.2 high · 145 in wheelbase
- Cargo
- 52.8 cu ft (bed volume, 5.5 ft box)
- Towing, max
- 12,700 lb
- Payload, max
- 2,030 lb
- Fuel tank
- 23 US gal
- EPA economy
- 17 city / 23 hwy / 19 combined mpg
- NHTSA overall
- 5 of 5 stars
- Fuel
- Gasoline
- Economy
- 17 city / 23 highway
- Odometer
- 68,420 mi
- Exterior
- Race Red
- Interior
- Black leather
- VIN (masked)
- 1FTEW1E4•••••412
- Title
- Clean · Florida, in hand
- Previous owners
- 1
- Days on lot
- 18
HIGHLIGHTS
- One owner, dealer-serviced
- Tow package with trailer brake controller
- New Michelin Defender set at 64k
PAPER FILE
Service history
4 RECORDS
- 68,420 mi Our intake: compression, leak-down, alignment sheet, fluids In-house bay
- 64,110 mi Oil and filter, tyre rotation Dealer stamp
- 55,980 mi Rear brake pads, brake fluid flush Dealer stamp
- 43,150 mi Transmission fluid service, spark plugs Dealer stamp
INSPECTOR NOTES
- The 3.5 EcoBoost is the desirable engine for towing; cam phaser noise was checked cold and is absent.
- Bed has a spray-in liner from new and no fifth-wheel holes.
HANDOVER
What leaves with the car
4 ITEMS
-
DOC-01
The inspection sheet
All 120 points with the measured values, photographs and the defect log — printed and emailed.
-
DOC-02
The paper file
Title, service records, prior invoices, recall status and the purchase order in one folder.
-
DOC-03
The measurement log
Compression, alignment, battery and paint depth readings, kept as a spreadsheet you can hand to your own mechanic.
-
DOC-04
The 30-day window
Powertrain coverage for thirty days, stated on the purchase order, honoured in our own bay.
